TEXAS INSTRUMENTS &ndashThe TTL Data Book for Design Engineers & (Catlett, VA)

TEXAS INSTRUMENTS &ndashThe TTL Data Book for Design Engineers &

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7245Illustrated Charts Graphs Device Description and Package Type Function Tables Device pin-outs Typical Characteristics Clock Requirements Electrical Characteristics Schematics (each gate) Recommended Operating Conditions Functional Block Diagrams.THE TTL DATA BOOK SECOND EDITIONIn this 832 page data book Texas Instruments is pleased to present important technical information on the industry s broadest and most advanced families of TTL Integrated circuits.You ll find complete specifications on standard technology TTL circuits (Series 54 74 Series 54H 74H Series54L 74L) and on TI s high-technology TTL circuits such as the Schottky-clamped Series 54LS 74LS and Series 54S 74S. Information on radiation-hardened and beam-lead circuits has not been included in this book but TI has a broad line of these devices and information is available upon request.The indexes are designed for ease of circuit selection with margin tabs to guide you quickly to general circuit categories and the alphanumeric and functional indexes will let you locate specific circuit types quickly. In addition a section showing pin assignments package availability and a brief description of the circuit type arranged in type-number order is included for quick reference. Whenever practical the MSI functions are arranged in sequence by type number to further simplify the task of locating a particular function.Contents by Chapter (in brief)INDEXES Alphanumeric Functional Selection Guide INTERCHANGABILITY GUIDE GENERAL INFORMATION ORDERING INSTRUCTIONS AND MECHANICAL DATA 54 74 FAMILIES OF COMPATABLE TTL CIRCUITS 54 74 FAMILY SSI CIRCUITS 54 74 FAMILY MSI LSI CIRCUITS JAN MIL-M-38510 INTEGRATED CIRCUITS 38510 MACH IV PROCUREMENT SPECIFICATIONS IC SOCKETS AND INTERCONNECTING PANELS Paperback 832 pages
