TEXAS INSTRUMENTS &ndash The Linear Control Circuits Data Book f (Catlett, VA)

TEXAS INSTRUMENTS &ndash The Linear Control Circuits Data Book f

Local pick up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7546Illustrated Charts Graphs Temperature Range (Military Automotive Industrial Commercial) for every device and Package Type Package Type Dual in-line packages (14 16 18 20 and 40) Flat Packages 10 14 and 16) Temperature Derating Curve by type (Plastic Ceramic and Flat) Device package pin-outs and dimensions Absolute Maximum Ratings over operating free-air temperature range electrical characteristics Typical Application Data Internal schematic of device pin connections INTRODUCTIONIn this 416-page data book Texas Instruments is pleased to present important technical information on a broad line of linear control integrated circuits that includes operational amplifiers voltage comparators analog switches timers analog-to-digital converters Hall-effect devices and many othersYou will find on device types initiated by TI (TL series) and on plug-in- replacements for many competitive types. The functionl indexes and selection guides provide the designer with rapid access to data sheets for specific applications and the interchangeability guides shows both direct and nearest replacement devices for many competitive parts. There are margin tabs to guide you quickly to general circuit categories and the alphanumeric index lets you locate particular type numbers quickly.The section on military products describes process and screening requirements for JAN JAN-processed 883B Class B and standard device types.This volume offers design data and specifications not only for linear control linear circuits but complete technical data technical data on any Texas Instruments semiconductor component is available from your nearest TI fiels sales office or authorized distributor and from Marketing and Information Services Texas Instruments Incorporated P.O. Box 225012 MS308. Dallas Texas 75265.Contents by Chapter (in brief)GENERAL INFORMATION THERMAL INFORMATION ORDERING INSTRUCTIONS AND MECHANICAL DATA OPERATIONAL AMPLIFIERS VOLTAGE COMPARATORS SPECIAL FUNCTIONS MILITARY PRODUCTS Paperback 416 pages
