Fairchild &ndash Diode Data Book © 1978 (Catlett, VA)

Fairchild &ndash Diode Data Book © 1978

Local pick-up preferred (please call first) but will ship at the buyers expenseIllustrated Charts Graphs Electrical Characteristic Curves Absolute Maximum Ratings Device Dimensions and Outlines Diode Array Dimensions Sample Circuits Component Testing Circuits Noise Density Measurement Circuit Block DiagramsKingston Books 15 IMG_7558INTRODUCIONFairchild Camera and Instrument Corporation is one of the largest suppliers of standard and high reliability diodes. Our broad line consists of small signal and switching diodes zener diodes diode arrays diode assemblies and rectifiers. Through design and process improvements Fairchild has consistently been able to deliver excellent quality. Low cost diodes in high volume.This data book is designed to make the selection of diodes very simple. Information is complete and arranged for your convenience.It contains Numeric Index of Devices for quick location of data.Device Selection Guides by application and product.Industry Cross Reference Industry vs Fairchild recommended part.Reliability Information Basis of Fairchild quality.Product Information Complete data sheets on all standard devices arranged numerically.Family Curves data sheets reference applicable curves.Sales Contacts addresses of Fairchild Sales Offices Sales Representatives and Fairchild Franchised Distributors.As well as supplying a complete line of standard devices. Fairchild is capable of supplying custom devices tailored to your application. The factory will evaluate your print and recommend the best. most cost effective device.Contents by Chapter (in brief)Numerical Index of Devices ..viCHAPTER 1.- Selection Guides ..1-3CHAPTER 2 Reliability ..2-3CHAPTER 3 PRODUCT INFORMATION Data Sheets ..3-3CHAPTER 4 FAMILY CURVES ..4-3CHAPTER 5 DIODE GLOSSARY OF SYMBOLS AND TERMS ..5-3CHAPTER 6 FAIRCHI D FIELD SALES OFFICES SALES REPRESENTATIVES AND DISTRIBUTOR LOCATIONS ..5-3Paperback 182 pages
