TWO Copies -FAIRCHILD &ndash FULL LINE CONDENSED CATALOG © 1 (Catlett, VA)

TWO Copies -FAIRCHILD &ndash FULL LINE CONDENSED CATALOG © 1

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7559Illustrated Charts Graphs Devices Listed for the Consumer Market Devices Listed for the Military Market All the microprocessor have block diagrams which display their common and different features Device pin-outs are shown the pin assignments are numbered and their corresponding connections to the package are listed in a table below the device and what signals appear on those pins.Micromachines Section11The Micromachine devices are complete 8-bit microcomputers on a single MOS integrated circuit. The family can execute the F8 instruction set of more han 70 commands allowing expansion into multi-chip configurations with software compatibility. The devices feature read only memory 64 bytes of scratchpad RAM a programmable binary timer 32 bits of I O and a single 5 V power supply requirement. Members of the family differ in memory type and size.Contents by Chapter (in brief)SECTION 1 PRODUCT INDEX ..1-3SECTION 2 DIODES Computer Diodes ..2-3SECTION 3 TRANSISTORS POWER Power Transistors (by Ic max Polarity and Ascending Vceo ..3-3SECTION 4 OPTOELECTROMICS LED Visible Lamps ..4-3SECTION 5 CHARGE-COUPLED DEVICES Linear Image Sensors ..5-3SECTION 6 HYBRIDS INTERFCE High Current Drivers ..6-3SECTION 7 LINEAR Voltage Regulators ..7-3SECTION 8 INTERFACE Line Drivers Receivers Transceivers Line Drivers ..8-3SECTION 9 DIGITAL TTL SSI Functions ..9-3SECTION 10 MEMORIES Random Access Memories Bipolar RAMs ..10-3SECTION 11 MICROCOMPUTERS MicromachineTM Series MicromachineTM ..11-3SECTION 12 AEROSPACE AND DEFENSE JAN QPL Status Linear ..12-3SECTION 13 LOGIC CONNECTION DIAGRAMS Optoelectronics ..13-3SECTION 14 ORDERING INFORMATION AND PACKAGE OUTLINES ..14-3SECTION 15 FAIRCHILD FIELD SALES OFFICES REPRESENTATIVES AND DISTRIBUTORS ..15-3Paperback 530 pages
