TEXAS INSTRUMENTS &ndash The Memory Interface Data Book for Desi (Catlett, VA)

TEXAS INSTRUMENTS &ndash The Memory Interface Data Book for Desi

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15- IMG_7570Illustrated Charts Graphs Device Description and Package Type Truth Tables and Test Tables Device pin-outs Typical Characteristics Clock Requirements Electrical Characteristics Schematics (each gate) Recommended Operating Conditions Functional Block Diagrams Thermal Resistance (by package type- J JG L N P) Temperature Derating Curves Ordering Instructions and Mechanical Data Package Internal Logic Schematics Switching Characteristics DC Test Circuits Definition of input logic levelsContents by Chapter (in brief)Alphanumeric Index ..8Interchangeability Guide ..9Thermal Information ..19Ordering Instructions and Mechanical Data ..25Sense Amplifier Selection Guide ..32Sense Amplifier Data Sheets SN5520 SN7520 Dual-Channel Sense Amplifiers with Complimentary Outputs ..33MOS Driver Selection Guide ..94MOS Driver Data Sheets SN55180 SN75180 Dual NAND TTL-to-MOS Level Converters ..97Memory Driver Selection Guide ..190Memory Driver Data Sheets SN75324 Memory Core Driver with Decode Inputs ..191Selection Guide for Other Interface Circuits ..224Texas Instruments reserves the right to make changes at any time in order to improve design and to supply the best products possible.TI cannot assume any responsibility for any circuits shown or represents that they are free from patent infringement.Information contained herein supercedes previously published data on Memory Interface Circuits Including data book CC-415 1977Texas Instruments IncorporatedPaperback 232 pages
