OKI SEMICONDUCTORS &ndash MICROCONTROLLER DATA BOOK © 1986 (Catlett, VA)

OKI SEMICONDUCTORS &ndash MICROCONTROLLER DATA BOOK © 1986

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7586Heavily Illustrated Charts Graphs Tables Device pin-outs Functional block diagrams Logic symbols Pin configurations Pin descriptions Functional description Instructional description Instruction set Absolute maximum ratings Operating conditions .A.C.& D.C. characteristics Timing Charts Typical performance curves Operating range Switching characteristics Description of terminals Typical Application Installation method for external ROM Package dimensionPREFACEA high technology company with an aggressive approach to innovation OKI electric industry co. ltd. has been supplying single chip microcontrollers since 1975. OKI single chip microcontrollers are widely applied to various types of electronic equipment both in the consumer field and the industrial field. In these fields our products have been enjoying a good reputation for their high quality and high performance. The most outstanding feature employed in all line up of OKI microcontrollers is CMOS technology which ensures low power operation in the electronic equipment OKI will furthermore continue to enhance the OKI microcontroller series and program development systems to cater for customers requirements.Contents by Chapter (in brief)PROGRAM DEVELOPMENT SYSTEM ..1 LINE UP AND TYPICAL CHARACTERISTICS ..5CODE ENTRY ..11PACKAGING ..15DATA SHEET ..25PROGRAM DEVELOPMENT SUPPORT SYSTEM ..215 OLMS-40 SERIES OLMS-50 60 SERIES OLMS-64 SERIES OLMS-65 SERIES 8 BIT SERIESCharts for the above seriesDATA SHEET ..25 OLMS-40 SERES ..27 OLMS-50 60 SERIES ..65 OLMS-64 SERIES ..113 OLMS-65 SERIES ..151 8 BIT SERIES ..161OKI makes no warranty for the use of its products and assumes no responsibility for any errors which may appear in this document nor does it make a commitment to update the information contained herein.OKI retains the right to make changes to these specifications at any time without notice.Paperback 263 pages
