Like New - HEATHKIT MANUAL FOR THE COLOR GENERATOR &ndash MODEL

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7590TABLE OF CONTENTSParts List ..3Assembly Notes ..10Step-by-Step Assembly Video Circuit Board Assembly ..13 RF Oscillator circuit Board Assembly ..21 Final Wiring ..29 Housing Assembly ..36Initial Tests and Adjustments ..38Final Assembly ..41Operation ..43In Case of Difficulty ..45 Troubleshooting Chart ..46Specifications ..49Circuit Description ..51Circuit Board X-Ray Views ..52Schematic ..54Component Identification Charts ..56Warranty ..Inside front coverCustomer Service ..Inside rear cover58 pages

24-12-2025 UNITED STATES, Catlett, VA
