TELEDYNE SEMICONCUCTOR DATA ACQUISITION IC HANDBOOK © 1986 (Catlett, VA)

TELEDYNE SEMICONCUCTOR DATA ACQUISITION IC HANDBOOK © 1986

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7718Illustrated Charts Graphs Tables Block Diagrams Sample Circuits Package Types & Outlines Pin designations Mechanical drawings Testing Soldering Removing Residual Flux (some methods are better than others) Absolute Maximum Ratings Electrical Characteristics Peak Current Limit Setup Output Shutdown Soft Restart from Shutdown Soft Start Power-Up Current Sense Amplifier Under Voltage Lockout Circuit Synchronization Typical Characteristic Curves (Using an Oscilloscope) Truth Tables Advanced Product Information Measurement Options AC to DC Measurements Conversion Timing Automatic Range Selection Operation LCD Displays External Crystal Dual Slope Conversion Principles .1986 Data and Design ManualContents by Chapter (in brief)Section 1. Table of Contents ..1-3Section 2. Ordering Information Package Drawings ..2-3Section 3. Quality Assurance Program ..3-3Section 4. Alphanumeric Product List ..4-3Section 5. Cross Reference Guide ..5-3Section 6. Advanced Product Information ..6-3Section 7. Display A D Converters ..7-3Section 8. Binary A D Converters ..8-3Section 9. Voltage to Frequency Frequency to Voltage Converters ..9-3Section 10. Display Drivers ..10-3Section 11. Interface ICs ..11-3Section 12. References ..12-3Section 13. Operational Amplifiers ..13-3Section 14. Digital Logic ..14-3Section 15. Application Notes ..15-3 Section 16. Glossary of Terms and Abbreviations ..16-3Section 17. Distributors and Representatives ..17-3Teledyne Semiconductor reserves the right to make changes in the circuitry or specifications detailed in this manual at anytime without notice. Minimums and maximums are guaranteed. All other specifications are intended sd guidelines only. Teledyne Semiconductor assumes no responsibility for the use of any circuits described herein and makes no representations that they are free from patent infringement.Paperback 628 pages
