Texas Instruments - The Memory Interface Data Book for Design En (Catlett, VA)

Texas Instruments - The Memory Interface Data Book for Design En

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7720Illustrated Charts Graphs Tables Package descriptions labeled pin-outs and sample circuits Memory Interface Circuits Thermal Information (pages 19 through 22)) Reference voltage considerations Input line layout considerations Sense input termination resistor considerations input drive capability logic input current requirements Absolute maximum ratings over operating free-air temperature range (unless otherwise noted) Recommended operating condition Function tables definitions of input logic levels electrical characteristics over recommended operating free-air temperature-range Vcc 5V Vcc- -5V TA 25 C (unless otherwise noted) schematic representations of the internal electronics inputs and outputs and the electrical connections of the package switching characteristics typical recovery and cycle times Vcc 5V Vcc - 5V Cext > 100pF TA 25 C Parameter Measurement Information (pages 52 through 75) Typical Characteristics Charts (page 76 through 78) small memory systems (page 81) large memory systems (page 81) design characteristics (page 84) Recommended operating conditions Precautions voltage waveforms MOS Drivers (pages (94 and 95) Package types and their dimensions Typical Characteristics Graphs Typical Application Data Parameter Measurement Information Thermal Information Maximum Safe Operating Area and Recommended Operating Area Table of Contents (in brief)Alphanumeric Index ..8Interchangeability Guide ..9Thermal Information ..19Ordering Instructions and Mechanical Data ..25Sense Amplifier Selection Guide ..32Sense Amplifier Data Sheet SN5520 SN7520 Dual Channel Sense Amplifiers with Complementary Outputs ..33MOS Driver Selection Guide ..94MOS Driver Data Sheets SN55180 SN75180 Dual NAND TTL-to-MOS Level Converters ..97Memory Driver Data Selection Guide ..190Memory Driver Data Sheets SN75324 Memory Core Driver with Decode Inputs ..191Selection Guide for Other Interface Circuits ..224IMPORTANT NOTICESTexas Instruments reserves the right to make changes at any time in order to improve design and to supply the best product possible.TI cannot assume and responsibility for any circuits shown or represent that they are free from patent infringement.Information contained herein supercedes previously published data on Memory Interface Circuits including data book CC-415Paperback 232 pages
