Tri-Ex&trade Towers © 1983 (Catlett, VA)

Tri-Ex&trade Towers © 1983

Local pick-up preferred (please call first) but will ship at the buyer s expense.Illustrated Charts Graphs TablesKingston Books 15 IMG_7755Illustrated Typical Installations Dimensions Specifications Mechanical Drawings & Information Guy Line Locations on both the tower & the ground Contents by Chapter (in brief)Self Supporting Crank-Up TowersLIL GiantMW SeriesGuying Kits For MW Series TowersW SeriesLM SeriesCrank-Up Accessories (For MW W & LM Series)Thrust Bearing (W & LM Series)Co-Ax Standoff Kits (MW W & LM Series)Antenna Mast (MW W & LM Series)Heavy Duty MastsWork PlatformsTilt-Over AccessoriesGin Pole Erection FeaturesBases For W & LM Series TowersMotor Control KitsManual Control Motor Kit with Top Limit SwitchManual Control Motor Kit with Top and Bottom Limit Switch (For towers having a 40 1 winch ratio)Remote Control Kit Less Motor ((Tower must have a pull-down assembly)Winch Conversion Kit Less MotorWinch and Motor KitsSafety Lock FixturesMast AdaptorsWall BracketsTM Sky Needle SeriesTM Sky Needle AccessoriesSKY NEEDLE MASTSMAST ADAPTORS ( For non-rotator usage)CO-AX STANDOFF KITSPERSONNEL LADDER (To first level only)WORK PLATFORMGIN POLE ERECTION FEATUREROTATOR MOUNTING ASSEMBLIESMOTOR CONTROL FOR TM-358REMOTE CONTROL KITSTACKED TOWERS & PARTSMODEL Z-10MODEL Z-10TMODEL Z-10CZ-10 GUYED TOWER KITSZ-10 C GUYED TOWER KITSMODEL T-9 .. (page T91-683)MODEL T-15 ..(page T151-683T-15 GUYED TOWERWT-51 ..(page WT511-683)ACCESSORIES ..(page WT-512-683)W-67 ..(page W671-683)ACCESSORIES ..(page W672-683)MODEL LM Self-Supporting Tower HAM & INDUSTRIAL CRANK-UP TILT-OVER TOWER ..(page LM1-683)ELECTRIC REVERSABLE WINCH ..(page EW1-683)MODEL TC-1500-BP -12 VOLT WINCH UNIT WITH POWER SUPPLY KIT (page EW2-683-3)MODEL TDD-1000 DRILL DRIVEN WINCH (NOTE DRILL MOTOR NOT SUPPLIED WITH WINCH UNIT) ..(page DW1-683)SAFETY LOCK FIXTURE FOR CRANK-UP TOWER ..(page SL1-683)SKY NEEDLE TOWERS ..(page TM1-683)FACTS ABOUT the Sky Needle Towers ..(pages TM4-683 through TM8-683)ClemenTower ..(pages CT1-683 through CT7-683)Technical Data Bulletin (pages ED-1-683 through ED2-683 Z101-683 & Z102-683)LI L GIANT MODEL ED40 ..(page ED-1-683 & ED2-683)PRICE SCHEDULE ..(pages 1 through 4))KITS COME COMPLETE WITH TOWER SECTIONS FOUNDATION BOLTS TOP PLATE MAST ANCHOR PLATE BASE ANCHORS AND ALL GUYING HARDWARE Tri-Ex and EIA recommended grounding the towers and the guy anchors. However this material is not included in the price of the kits. See price list for grounding material.The information contained in these drawings or data sheets it s the property of Tri-Ex Corp and cannot reproduced or used without the written permission of Tri-Ex Tower Corp as it refers to patent applications submitted or in preparation.WARNING When erecting a tower first look for power lines. Avoid contact of tower sections and guy wires to power lines. Contact to power lines can be fatal. Tower site should be far enough away from power lines so that in the event of a tower fall the tower and guys will not contact a power line.Paperback 30 pages
