THE CANNON CONNECTION &ndash Cannon Standard Line Connectors Cat (Catlett, VA)

THE CANNON CONNECTION &ndash Cannon Standard Line Connectors Cat

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7860Illustrated Charts Specialized Hand tools Standard Materials and Finishes Mechanical Features Shell Styles and Contact Type Insulator Material Number of Contacts Contact Arraignments Contact Termination Test Data Standard Data Assembly Instructions Accessory Hardware Contents by Chapter (in brief)Circular Connectors.....(page 11)CA Bayonet Standard Circular Series .. (page 2)CA-KE Standard Circular Series . (page 5)CV MIL-C-5015G Standard Circular Series .. (page 9)CVA M83723 Standard Circular Series .. (page 17)FRF FVF FRA FVA Standard Circular Series .. (page 26)K SERIES lightweight rugged connectors with quick connect disconnect Acme threads .. (page 34)KO MC Miniature Circular Series heavy duty and light weight general purpose. Acme threads and solder contact terminations .. (page 43)KJL KJ MIL-C-38999 Subminiature Circular Series high performance high contact density lightweight bayonet coupling rear release crimp snap-in contacts .. (page 49)KPT KPTM KPSE KTN KTNM MIL-C-26842 Miniature Circular Series general purpose solder and crimp removable contacts .. (page 63)MB Waterproof Series designed to meet MIL-C-5015 and withstand severe environmental conditions involving mud ice and water .. (page 77)MS-A MS-B MS-E MS-F ER Standard Circular MIL-C 5015 Series General purpose threaded coupling solder and crimp removable contacts ..(page 80)MS-K Standard Circular series MIL-C-5015 firewall connectors with crimp and thermocouple contacts ..page 100)PV Miniature Circular Series designed to M83723 (Series I) and M26482 (Series II) with bayonet coupling..... (page 104)PVW PVX Miniature Circular Series designed to M-0026482 NAS1599 M83723 (USA) and various European ml specs bayonet coupling hermetic versions are available ..(page 113)SRCN SRC Miniature Circular Series rugged low cost general purpose connectors used in measurement and test equipment communications systems medical equipment and other general industiral equipment applications ..(page 114)Sure Seal Series - low cost UL CSA recognized sealed connectors for automotive industrial applications ..(page 117)VE Standard Circular Series sealed connectors that meet all the needs of the heavy duty transportation industry .. (page 122)XLR XLB Miniature Circular Series connectors used in commercial industrial electronics and audio video applications ..(page 125)RECTANGULAR RACK PANEL CONNECTORSBKAD E Series environmental and non-environmental rectangular ARINC 600 connectors with low insertion force contacts ..(page 125)CM Series low cost easy to assemble modular concept of block building connectors .. (page 130)D Subminiature Series rectangular connectors for commercial industrial and general military aero space MIL-C-24038 applications .. (page 142)DPK Series high performance rack panel environmental-resistant thermal protection connectors qualified to MIL-C-83733 (USAF) ..(page184)DPXNA DPNXE Series single 2- 3- 4 gang rack panel non-environmental environmental versions deigned to meet MIL-C-81659 Rev. B ..(page 195)PRINTED CIRCUIT EDGECARDADAPTA-CON Series low force receptacle and post interconnections for PC and I O applications .. (page 205)DL ZIF Series designed for commercial industrial computer and peripheral equipment zero mating force via cam actuated contacts .. (page 214)IDC Series insulation displacement connector packaging system for telecommunications computer industrial control and other applications requiring low cost with high performance high speed mass termination of contacts ..(page 225)EDGECARD Series direct indirect discrete and back-panel types accommodating from 2 to 200 contacts in gold silver or tin plating contact spacings from .100 to .200 inches solder eyelet or wrap post terminations commercial military and DIN types available ..(page 229)HERMETICD Subminiature Series qualified to MIL-C-24308 hermetically sealed and designed to meet environmental conditions of extreme pressure differential .. (page 241)MC KH Miniature Circular Series fro both commercial and military applications in instrumentation machine tools automotive and military guidance systems .. (page 241)K Standard Circular Series rugged lightweight connectors with special Acme threads used on aircraft transmitters television cameras and other equipment ..(page 241)KPT PVA Miniature Circular Series MIL-C-26482 (Series I and II) connectors having broad base commercial military and industrial applications .. (page 242)KJLY KJY Miniature Circular Series designed to MIL-C-38999 and readily adaptable to space age requirements where size weight and high reliability are key factors ..(page 243)GS Standard Circular MIL-C-5015 Series designed for applications where a vacuum. Inert gas or a constant or controlled pressure are required .. (page 244)FilterD J Subminiature Rectangular Series filtered equivalent to MIL-C-24308 types used where space and weight are prime considerations .. (page 246)DPXJ Miniature Rectangular Series meets requirements of ARINC 404 and intermateable with standard DPX connectors used primarily on commercial and military aircraft for radio and instrumentation equipment ..(page 246)KJJL KJJ Miniature Circular Series low-profile high contact density environmental connectors designed to meet MIL-C-38999 specifications .. (page 246)PVJ Miniature Circular Series designed to meet the applicable portions of MIL-C-26482 and MIL-C-83723 intermateable with NAS1599 and NAS 40M35969 type connectors .. (page 246)MICROMINATURERectangular circular strip configurations featuring high contact density with MICRO (3 amp) Centi (5 amp) and NANO (1 amp) twist pin contacts) .. (page 248)CONNECTOR SELECTION GUIDEAn abbreviated connector guide listing additional product catalog information for products not shown in this catalog (page 284)ITT Cannon manufactures the finest quality products available to the marketplace however these products are intended to be used in accordance with the specifications described in this catalog. Any use or application that deviates from the stated operating specifications is not recommended and may be unsafe. A limited warranty applies to ITT Cannon products. Except for obligations assumed by ITT Cannon under warranty ITT Cannon will not be liable for any loss damage or cost of repairs incidental or consequential damages of any kind whether or not based upon express or implied warranty contract negligence or strict liability arising in connection with the design manufacture sale use or repair of the products.Paperback 285 pages
