NEAR MINT CONDITION - HEATHKIT MANUAL for the HD-1410 ELECTRONIC

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston BOOKS 15 IMG_7830Illustrated Block Diagram Circuit Description INTRODUCTION (in brief) .. (page 2)The HD-1410 is compact Electronic Keyer with a built-in AC power supply mechanical paddles sidetone oscillator and speaker in one package. It is designed and styled to compliment the SB Series and is compatable with virtually all modern transmitters and transceivers as well as most older rigs.TABLE OF CONTENTS (in brief) (and page numbers locations)Introduction ..2Parts List ..3Step-by-Step AssemblyCircuit Board Assembly ..15Tests and Adjustments ..46Final Assembly ..49Installation ..52Operation ..54In Case of Difficulty ..55Troubleshooting ..56Specifications ..58Circuit Description ..60Circuit Board X-Ray Views ..64Circuit Board Voltage Chart ..66Chassis Photograph ..67Identification Chart ..68Schematic (fold-out page) ..71Warranty ..Inside front coverCustomer Service ..Inside back coverPaperback 70 pages
