Coilcraft Inductors &ndash fixed and adjustable (Catlett, VA)

Coilcraft Inductors &ndash fixed and adjustable

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7886Illustrated Charts Graphs Mechanical and Electrical Specifications Dimension information Schematics Typical Electrical Characteristics Construction InformationInductor Types and other Devices listed in sequence in the catalog (in brief)FixedChipInductive Devices for Video DisplaysInductive Devices for Switching Power SuppliesStructured Design of Power Magnetics35 Watt 3 Output Switching SupplyPower Inductor Design InformationCommon Mode Line Choke InformationCurrent Sensor Specification SheetUnicoils10 Millimeter CoilsMagnetic Heads (for devices using magnetic taped)Coilcraft is one of the world s leading suppliers of inductive devices to the electronics industry. Coilcraft products are used in video displays electronic power supplies communications data processing and consumer and home entertainment products.With more than 30 years of inductive experience Coilcraft has earned a reputation for quality engineering and service. Coilcraft innovations and standardized design approaches have consistently benefited customers with production economies short leads times and good prices.Coilcraft engineers personally help you select the most economical and reliable coil design for your circuit application. Our engineers are ready to design inductive devices of practically any mechanical and electrical specification to meet your particular requirements.Coilcraft has high-volume manufacturing capacity with both domestic and of-shore production facilities. These plants located in Illinois Iowa Mexico and Taiwan give you multiple sourcing and pricing for your inductor needs. Coilcraft quality procedures comply with military and commercial specifications.Coilcraft is the most versatile company in the coil business manufacturing an extensive line of inductive devices including Fixed Inductors Variable Inductors Chip Inductors 10 mm Coils Linearity Coils P C Board Assemblies Switch Mode Transformers Toroidal Windings Pin Cushion Transformers Filters Radiation Chokes Delay Lines Magnetic Recording HeadsTo assist customers in making their inductance decisions Coilcraft offers a wide range of sample kits of its parts. The pre-engineered coils in these kits allow your project engineers to conduct circuit design experiments without having to wait for special samples and prints. Kits may be ordered for a modest price. For more complete information on Coilcraft inductors including specifications and ordering information. Please call or write us.Coilcraft1102 Silver Lake RoadCary Illinois 60013(312) 639-2361Loose leaf vinyl binder 50 pages
