Molex ® C-Grid and C-Grid SL Interconnection Systems ©198

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_8004Illustrated Charts Dimensions Material Specifications Interconnection wire sizes DrawingsContents by ChapterFlow Chart C-Grid SL ..7Specifications Female and Male Crimp Terminals ..8Female Crimp Terminal ..9Male Crimp Terminal ..10Dual Row Crimp Connector Housing.....11Single Row Crimp Connector Housings ..12-15Specifications Single Row Female Insulation Displacement Connector Assemblies ..16Illustrations of Assemblies ..17Single Row Female Connector Assemblies ..18-25Dual Row Insulation Displacement Connector C-Grid ..26Dual Row Board-to-Board Connector ..27Specifications Male Insulation Displacement Connector Assemblies ..28Illustrations of Assemblies ..29Single Row Male Connector Assemblies ..30-35Specifications Single and Dual Row Headers ..36Illustrations of Assemblies ..37.120 Pocket Straight Shrouded Headers ..38-45.120 Pocket Right Angle Shrouded Headers ..46-53.180 Pocket Straight Shrouded Headers .54-61.180 Pocket Right Angle Shrouded Headers ..62-69Dual Row Shrouded Headers ..70-71Dual Row Straight pin Breakaway header ..72Dual Row Right Angle Breakaway Header ..73Dual Row Right Angle Header ..74Dual Body Header ..75Single Row Straight Pin Breakaway Header ..76Single Row Right Angle Breakaway Header ..77Wire-to-Wire Connector ..78-79Single Row Discrete Branch Panel Mount ..80-81Single Row Modular Branch Panel Mount ..82-83Discrete Wire Panel Mount ..84-85Dual Row Modular Branch Panel Mount ..86Single and Dual Row Interim Clips ..87-89Shunt or Jumper ..90Block Splice ..91Crimp and Insulation Displacement Termination Tooling ..92-94All information contained herein including illustrations specifications and dimensions is believed to be reliable as of the date of publication but is subject to change without notice. Current sales drawings and specifications are available upon request. Molex makes no claims or warranties as to the application of these products or their suitability or fitness for any particular purposes. Accordingly it is recommended that each user independently test and evaluate products for their intended use94 pages
