Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_8016IllustratedBerg Electronics offers the widest variety of modular jacks available to the industry. These female jacks provide total modular interconnect by accepting both ends of reeiver and line cord plugs of any standard telephone style.The heart of the modular concept is a male plug and mating female jack receptacle and mating female jack receptacle. The female jack assembly consists of 27AWG stranded wire leads terminated on one end with a spade lug and a gold plated spring wire spliced to the other. These leads are positioned within a molded plastic housing to complete the jack assembly.Telephone operating companies benefit from the modular concept by a significant reduction of installation maintenance and repair costs. The telephone subscriber also benefits as it allows him to snap the telephone together at his location saving time and money with added convenience.Table of ContentsIntroduction & Specifications ..4 5616W Transmitter Mount Handset Cord Connector ..6 7616 Series Base Mount Handset Cord Connector ..6 7 8 9227 Adapter ..8 9623 Series Base Mount Line Cord Connector ..10 11523 Series Base Mount Line Connectors ..10 11625 Series Wall Mount Line Cord Connectors ..12 13Inserts ..12 13 14 15P.C. Mount Series ..14 15Lead Assemblies ..1615 pages
