SGS TECHNICAL NOTE 165 Designing with the L296 Monolithic Power

Local pick-up preferred (please call first) but will ship at the buyer expenseKingston SGS Technical Note 165 IMG_8124Author G. GattavariPublisher SGS-ATES Group of CompaniesIllustrated Schematics Waveforms Device Description Oscillator PWM Soft Star Circuit Calculating the Duty Cycle and Soft Start Time Synchronization Current Limitation Crowbar Inhibit Thermal Protection Applications Resistor value or standard output voltages Switching vs. Linear Low Cost Application and Pre-regulation Power Supply Completer with Transformer Power Supply with Mains Switching Pre-regulator Power Supply with 0 -30V Adjustable Voltage Dual Output Regulator Battery Charger Higher Input Voltage Motor Control Step-up Converter Description of Operation Layout Considerations Typical Applications Circuit Heatsink DimensionsAppendix A Calculating System Stability Gain of the Pulse Width Modulation Block and Output Stage Error Amplifier DC Gain and Line regulation33 pages

08-05-2025 UNITED STATES, Catlett, VA
