NATIONAL SEMICONDUCTOR &ndash LOGIC DATABOOK. VOL 1 (Catlett, VA)

NATIONAL SEMICONDUCTOR &ndash LOGIC DATABOOK. VOL 1

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_6746Illustrated Sample Circuits where these ICs are used Contents by Chapter (in brief)CMOS AC Switching Test Circuits and Timing Waveforms CMOS Application Notes MM54HC MM74HC MM54HCT MM74HCT CD4- MM54C- MM74C- LSI VLSI Appendices Physical Dimensions This comprehensive databook provides information on National Semiconductor s advanced CMOS logic families MM54HC 74HC high speed CD4000 MM54C 74HC and the many unique CMOS LSI products. TheMM54HC 74HC family utilizes microCMOS technology to achieve the input and power supply characteristics of CMOS with the high speed and large output drive of low power Schottky. The MM54HC 74HC family has the same pinout as equivalent 54LS 74LS in addition many popular CD 4000 series logic functions are offered where no equivalent TTL function exists.Paperback 1602 pages
