Radio Shack (National Semiconductor) Voltage Regulator Handbook. (Catlett, VA)

Radio Shack (National Semiconductor) Voltage Regulator Handbook.

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7473Heavily Illustrated Sample Circuits Thermal Charts Custom Heat Sink Design Typical Performance Characteristics of each Device Physical Dimensions and Package Outlines Absolute Maximum ratingsContributors Nello Sevastopolous Jim Sherwin Dennis Bohn George Cleveland James SolomanHow To Use This BookThis manual has been created and arranged to simplify the task of selecting and appropriate three-terminal regulator according to your specific system needs. Information is also supplied on heat sink selection and design power transformer and filter specification and on various extended use applications for the basic three-terminal and dual tracking regulators.You will also find the following information covering the folloeing If a system already exists.If a higher current is required.Where a heat sink is required.For small systems using only one regulator or if a system supply does not yet exist.For applications other that simple three-terminal regulation.For voltage regulators at other than the voltage voltages listed.Ordering information.Test methods and circuits for testing.Cross reference listings to manufacturers other than National Semiconductor i.e. Raytheon Motorola TI and FairchildContents by Chapter (in brief)Introduction How to Use This Book ..1.1 Data Sheet Summary ..2-1 Production Selection Procedures ..3-1 Heat Flow and Thermal Resistance ..4-1 Selection of Commercial Heat Sink ..5-1 Custom Heat Sink Design ..6-1 Application Circuits And Descriptive Information .7-1 Power Supply Design ..8-1 Appendix Definition of Terms ..9-1 Data Sheets ..10-1 Paparback 102 pages
