MOTOROLA &ndash TELECOMMUNICATIONS DEVICE DATA © 1984 (Catlett, VA)

MOTOROLA &ndash TELECOMMUNICATIONS DEVICE DATA © 1984

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7501Illustrated Sample Circuits RECOMMENDED OPERATING CONDITIONS AND ABSOLUTE MAXIMUM RATINGS Device pin-outs Function Tables ELECTRICAL CHARACTERISTICS Test Circuits and Waveforms Typical Performance CharacteristicsMOTOROLA TELECOMMUNICATIONS DEVICE DATAMotorola is a major supplier of Semiconductors to Telecommunications equipment manufacturers worldwide and our data manuals for such standard products as dedicated MOS and Bipolar Telecom ICs CMOS Special Circuits High Speed CMOS ECL TTL Linear Power Transistors Microprocessors and Memories. are on the reference shelves of designers throughout the industry.This data book pulls together Motorola s Semiconductor Products which are dedicated to applications in Telecommunications and the need for designers to have product information at hand in a convenient form.Many of the products presented here are new for new applications in an industry which is presently one of the most dynamic and fastest growing Telecommunications. It was possible only to include a limited amount of application material. Hence these products are supported by applications and product specialists within the Motorola Semiconductor organizations. Should you require further details or assistance in designing with any of these devices your Motorola Semiconductor Sales Office can put you in touch with the relevant expertise within our organization.Motorola reserves the right to make changes to any product herein to improve reliability function or design. Motorola does not assume any liability arising out of the application or use of any product described herein neither does it convey any license under its patent rights nor the rights of others.Motorola Inc. general policy does not recommend the use of its components in life support applications where a failure or malfunction of the component may directly threaten life or injury. Per Motorola Terms and Conditions of Sale the user of Motorola Components in life support applications assumes all risk of such use and indemnifies Motorola against all damages.Contents by Chapter (in brief)Selection Guides Data Sheets Application Notes and Technical Articles Glossary Handling and Design Guidelines Quality and Reliability Mechanical Data Paperback 518 pages
