MOTOROLA &ndash RECTIFIERS AND ZENER DODES DATA © 1985 (Catlett, VA)

MOTOROLA &ndash RECTIFIERS AND ZENER DODES DATA © 1985

Local pick-up preferred (please call first) but will ship at the buyer s expense.Kingston Books 15 IMG_7502Illustrated Device Specifications and Charts (Max Current Transient Thermal Impedance Max Surge Current Typical Dynamic Characteristics - (Rectification Efficiency Reverse Recovery Time Junction Capacitance Forward Recovery Time) Power Dissipation Device Test Circuits (schematics) used for evaluationRectifiers pages 2 through 29Zener Diodes pages 30 through 62This book presents technical data for the broad line of Motorola Silicon Rectifiers and Zener Diodes. Complete specifications for individual devices are provided in the form of data sheets. In addition a comprehensive selector guide and industry cross-reference guide are included to simplify the task of choosing the best set of components required for a specific application.The information in this book has been carefully checked and is believed to be accurate however no responsibility is assumed for inaccuracies.Motorola reserves the right to make changes without further notice to any product herein to improve reliability function or design. Motorola does not assume any liability arising out of the application or use of any product or circuit described herein neither does it convey any license under its patent rights nor the rights of others.Motorola Inc. general policy does not recommend the use of its components in any life support application wherein a failure or malfunction of the component may directly threaten life or injury. Per Motorola Tems and conditions of Sale the user of Motorola components in life support applications assumes all risks of such use and Indemnifies Motorola against all damages.Contents by Chapter (in brief)Index and Cross-Reference Selector Guides Rectifier Data Sheets Zener Diode Data Sheets Paperback 510 pages
