NATIONAL SEMICONDUCTOR &ndash MM54HC74HC HIGH SPEED micro CMOS L (Catlett, VA)

NATIONAL SEMICONDUCTOR &ndash MM54HC74HC HIGH SPEED micro CMOS L

Local pick-up preferred but will ship at the buyer s expense.Kingston - Books 15 IMG_7495Illustrated Charts Graphs Block and Connection Diagrams Device Pin-Outs and Specifications Timing Waveforms Typical Performance Characteristics Truth Tables Functional Descriptions Physical DimensionsIntroductionThis comprehensive databook provides information on National Semiconductor s MM54HC MM74HC high speed CMOS family of SSI MSI LSI logic components. The family utilizes microCMOS Technology to achieve the input and output power supply characteristics of CD4000B CMOS with the high speed and large output drive of 54LS 74LS logic. This combination enables the construction of very high thru-put low power systems. The MM54HC MM74HC family has the same pin-out as equivalent 54LS 74LS functions in addition many popular CD4000 series logic functions are offered where no equivalent TTL function exists. Also this high speed logic family incorporates a growing number of new functions not previously implemented in either a CMOS ot TTL logic family.The MM54HCT MM74HCT are a subfamily of MM54HC MM74Hc offering TTL compatible inputs. These MM54HCT MM74HCT devices offer convenient TTL level translation to CMOS for those interface points where only TTL levels are provided i.e. NMOS microprocessor bus 54S 74S 54ALS 74ALS etc.The broad line of MM54HC MM74HC functions greatly simplifies the task of designing complete high speed systems in CMOS.Content by Chapter (in brief)Section 1. High Speed CMOS AC DiagramsSection 2. Application NotesSection 3. Connection DiagramsSection 4. MM54HC MM74HC Data SheetsSection 5. NN54HCT MM74HCT Data SheetsSection 6. Enhancement ProgramsSection 7. Reliability ReportSection 8. Ordering and Package InformationPaperback 580 pages
