MOTOROLA LINEAR SWITCH MODE VOLTAGE REGULATOR HANDBOOK 2nd Ed. 1982Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7505Illustrated Sample circuits Charts Graphs Device pictorials Design Considerations (General layout and component placement considerations) Component mounting details Waveforms Operating Temperature Considerations Electrical Characteristics Maximum Ratings Schematic DiagramsPREFACEIn most electronic systems voltage regulation is required for various functions. Today s complex electronic systems are requiring greater regulating performance higher efficiency and lower parts count. Present integrated circuit and power package technology has produced IC voltage regulators which can ease the task of regulated power supply design provide the performance required and remain cost effective. Available in growing variety. Motorola offers a wide range of regulator products form fixed and adjustable voltage types to special function and switching regulator control IC s. This handbook describes Motorola s voltage regulator products and provides information on applying these products. Basic Linear regulator and switching regulator topologies has been included along with practical design examples. Other relevant topics include trade-offs of Linear vs. switching regulators series pass elements for Linear regulators switching regulator component design considerations Heatsinking construction and layout power supply supervisory and protection and reliability. A Motorola regulator selector guide along with data sheets and an industry cross-reference are also contained in this handbook. A transistor and rectifier selector guide for switching regulators of various configurations configurations and power levels is provided in Appendix A and B.Contents by Chapter (in brief)Section 1. Basic Linear Regulator Theory ..1Section 2. Selecting a Linear IC Voltage Regulator ..11Section 3. Linear Regulator Circuit Configuration and Design Considerations ..15Section 4. Series Pass-Element Considerations for Linear Regulators ..37Section 5. Linear Regulator Construction and Layout ..51Section 6. Linear Regulator Design Example ..57Section 7. Linear Regulator Circuit Troubleshooting Check List ..61Section 8. Designing the Input Supply ..63Section 9. Switching Regulators vs. Linear Regulators ..73Section 10. Switching Regulator Topologies ..77Section 11. Switching Regulator Component Design Tips ..87Section 12. The Future for Switching Regulators ..103Section 13. Switching Regulator Design Examples ..105Section 14. Power Supply Supervisory and Protection Considerations ..121Section 15. Heatsinking ..135Section 16. Regulator Reliability ..145Section 17. IC Regulator Selection Guides ..151Section 18. Regulator Data Sheets ..161Section 19. Package Outline Dimensions ..369Section 20. Voltage Regulator Cross-Reference Guide 375Appendix A. Switchmode Power Transistor Application Selector Guide ..381Appendix B. Motorola Switchmode Rectifiers for Switching Power Supplies ..387 Paperback 390 pages
