MOTOROLA RF SEMICONDUCTORS DATA MANUAL - 2nd Edition © 1982 (Catlett, VA)

MOTOROLA RF SEMICONDUCTORS DATA MANUAL - 2nd Edition © 1982

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7518Illustrated Charts Graphs Device Package Overview Device Mounting Hardware Sample Circuits Maximum Ratings (Voltage Current and Power Dissipation) Thermal Characteristics Electrical Characteristics (Graphs) -> Output Power vs. Input Power Output Power vs. Supply Voltage Power Gain vs. Frequency Intermodulation Distortion vs. Output Power DC Safe Operating Area Test Circuit Schematics (by device and frequency) Test Amplifier PCB (Printed Circuit Board) Photomaster used to make circuit boards NOTE Printed Circuit Boards Layouts have been reduced. Full size layouts may be obtained by ordering the data sheet from your sales representative or authorized distributor or from Motorola Literature Distribution Center P.O. Box 20912 Phoenix AZ. 80536The second edition of the RF Data manual has been updated to incorporate the latest changes since the last printing. There are 251 devices and 10 application notes including tuning diodes hot-carrier mixed diodes PIN switching diodes and RF FETs.Motorola s RF family now includes 1.2 GHZ pulsed power devices to 325 W peak output 2.0 GHz CW broadband transistors up to 16W output low-cost general purpose hybrid amplifiers in TO-39 packages with bandwidths to 1.0 GHz and power amplifiers to 20 W output for the FM 806-870 MHz mobile band. Low noise small-signal microwave transistors in both plastic and hermetic stripline packages provide excellent cost effectiveness and JAN JTXV version for the hi-rel applications.The information in this book has been carefully checked and is believed to be reliable however no responsibility is assumed for any inaccuracies. Furthermore this information does not convey to the purchaser of microelectronic devices any license under the patent right of the manufacturer.Contents by Chapter (in brief)Selection Guide and Cross References 2-30 Mhz 12.5 Vdc 2-30 Mhz 28 Vdc 2-30 Mhz 50 Vdc 14 30 Mhz 12.5 Vdc 27 50 Mhz 12.5 Vdc 30 -200 Mhz 28 Vdc 66 88 Mhz 12.5 Vdc 130 175 Mhz 12.5 Vdc 225 Mhz 12.5 Vdc 225 400 Mhz 28 Vdc 407 512 Mhz 12.5 Vdc 806 870 Mhz 12.5 Vdc Microwave Power Transistors Hybrid Power Amplifier Modules Hybrid Linear Amplifier modules Small-Signal Low Power RF Field-Effect Transistors Tuning Hot-Carrier and PIN Diodes General Technical Information RF Transistor Design Reliability and Quality Assurance Paperback 1176 pages
