Signetics &ndash Bipolar Memory Data Manual © 1986 (Catlett, VA)

Signetics &ndash Bipolar Memory Data Manual © 1986

Local pick-up preferred (please call first) but will ship at the buyer s expenseKingston Books 15 IMG_7519Bipolar Memory ProductsRapid improvement in both the cost and performance of semiconductor memories has led to a dramatic increase in their usage in today s highly sophisticated electronic systems. Signetics has worked diligently over the last 23 years to develop the various technologies necessary to satisfy the broad range of user s semiconductor requirements. As a result Signetics has become a leading supplier of Bipolar Memories to the electronics industry.Signetics offers a complete line of Bipolar Schottky PROMs and RAMs for many high speed applications. These products are available with organizations ranging from 64 to 2k bits for the RAM family and 256 to 64K bits for the PROM family. All Signetics bipolar products are fabricated with double level metallization for maximum packaging density and low cost. Signetics will continue to advance Bipolar memory state of the art in future years through the introduction of new special purpose PROMs and high-speed RAMsThe 1986 Signetics Memory Data Manual contains data on currently available PROM and RAM products and some products which are planned for the immediate future in addition a product selection guide is included to aid the user in quickly selecting the optimum product for this particular application.Illustrated Charts Graphs Cross Reference Guide Ordering Information Block Diagrams Features Applications Device pin-outs Absolute Maximum Ratings Supply Voltage Input and Output Voltage Temperature range (operating and storage) AC and DC Electrical Characteristics Truth Tables Voltage Waveforms Timing Diagrams (both Read and Write Cycles).Contents by Chapter (in brief)Bipolar Memory ProductsSection 1. Quality and Reliability ..1-3Section 2. RAMs 64-Bit ..2-3Section 3. RAMs 256 Bit ..3-3Section 4. RAMs Byte-Organized ..4-3Section 5. PROM Programming Information Generic Programming Procedures ..5-5Section 6. PROMs Low-Complexity 256-Bit-Bipolar PROM (32x8) ..6-3Section 7. PROMs 4K-Bit - Bipolar PROM (512 x 8) ..7-3Section 8. PROMs 8K-Bit -Bipolar PROM (1024 x 8) ..8-3Section 9. PROMs 16K-Bit Bipolar PROM (2048 X 8) ..9-3Section 10. PROMs 32K-Bit Bipolar PROM (4096 x 8) ..10-3Section 11. PROMs 64K-bit Bipolar PROM (8192 x 8) ..11-9Section 12. Packages General Information ..12-3 Package OutlinesPlastic Leaded Chip Carrier ..12-5 Small Outline Large Dip ..12-6 Plastic Dip ..12-13 Cerdip ..12-8 Section 13. Sales Offices Office Listings ..13-3 Paperback 188 pages
